| WORKING BANDS | 900, 1800 MHz |
| UL FREQUENCY RANGE | 880-915/ 1710-1785 MHz |
| DL FREQUENCY RANGE | 925-960/ 1805-1880 MHz |
| SUPPORTED STANDARDS | EGSM + DCS/LTE |
| V.S.W.R | Typical≤2 |
| MAXIMUM GAIN | 65 db |
| MGC (STEP ATTENUATION) | ≥ 31 db/ 1 db step |
| INTELLIGENT AGC | ALC ≥42dB ISO ≥42dB |
| GAIN FLATNESS | Typical≤5dB (p-p) |
| NOISE FIGURE @ MAX. SYSTEM GAIN | Typical≤5dB |
| GROUP DELAY | ≤1μs |
| FREQUENCY STABILITY | ≤0.01ppm |
| POWER SUPPLY | Input AC 90~240 V, 50/60 Hz, Output DC 12V/3A |
| POWER CONSUMPTION | 10W |
| IMPEDANCE | 50 ohm |
| LCD DISPLAY | Frequency, Gain, Output Power, ALC, ISO indicators |
| I/O PORT | N-Female |
| DIMENSIONS | 4.7*7.8*1.3 inch/ 120*198*34mm |
| BOOSTER WEIGHT | ≤2.2lbs/ 1KG |
| BOOSTER KIT WEIGHT | 3.6 KG |
| OPERATING TEMPERATURE | -10ºC~+55ºC |
| STORAGE TEMPERATURE | -10ºC~+80ºC |
| RELATIVE HUMIDITY | 5% – 95% |
| BAROMETRIC PRESSURE | 55 kPa -106 kPa |
| ENVIRONMENT CONDITION | IP40 |
